Printronix P7000 Series Maintenance Manual page 405

V5 Controller Board (continued)
VDD
VCC1
NINTB
NINTD
NPRSNT0
NPRSNT1
CLK2
NREQ2
AD31
AD29
AD27
AD25
NC_BE3
AD23
AD21
AD19
AD17
NC_BE2
NIRDY
NDEVSEL
NPERR
NSERR
NC_BE1
AD14
AD12
AD10
AD8
AD7
AD5
AD3
AD1
0 Ohm
0W
0 %
SDA
J13
PCI Connection
B1 RSV RSV A1
B2 RSV RSV A2
B3 GND RSV A3
B4 RSV RSV A4
B5 5V 5V A5
B6 5V NINTA A6
B7 NINTB NINTC A7
B8 NINTD 5V A8
B9 NPRSNT1 RSV A9
B10 RSV 3.3V A10
B11 NPRSNT2 RSV A11
B12 KEY KEY A12
B13 KEY KEY A13
B14 RSV 3.3VAUX A14
B15 GND NRST A15
B16 CLK 3.3V A16
B17 GND NGNT A17
B18 NREQ GND A18
B19 3.3V NPME A19
B20 AD31 AD30 A20
B21 AD29 3.3V A21
B22 GND AD28 A22
B23 AD27 AD26 A23
B24 AD25 GND A24
B25 3.3V AD24 A25
B26 NC/BE3 IDSEL A26
B27 AD23 3.3V A27
B28 GND AD22 A28
B29 AD21 AD20 A29
B30 AD19 GND A30
B31 3.3V AD18 A31
B32 AD17 AD16 A32
B33 NC/BE2 3.3V A33
B34 GND NFRAME A34
B35 NIRDY GND A35
B36 3.3V NTRDY A36
B37 NDEVSEL GND A37
B38 GND NSTOP A38
B39 NLOCK 3.3V A39
B40 NPERR RSV A40
B41 3.3V RSV A41
B42 NSERR GND A42
B43 3.3V PAR A43
B44 NC/BE1 AD15 A44
B45 AD14 3.3V A45
B46 GND AD13 A46
B47 AD12 AD11 A47
B48 AD10 GND A48
B49 M66EN AD9 A49
B50 GND GND A50
B51 GND GND A51
B52 AD8 NC/BE0 A52
B53 AD7 3.3V A53
B54 3.3V AD6 A54
B55 AD5 AD4 A55
B56 AD3 GND A56
B57 GND AD2 A57
B58 AD1 AD0 A58
B59 3.3V 3.3V A59
B60 I2CDATA I2CCLK A60
B61 5V 5V A61
B62 5V 5V A62
Slot 2
VDD
VCC1
NIRQ2
NINTC
PCI_NRST
NGNT2
AD30
AD28
AD26
AD24
IDSEL2
AD22
AD20
AD18
AD16
NFRAME
NTRDY
NSTOP
PAR
AD15
AD13
AD11
AD9
NC_BE0
AD6
AD4
AD2
AD0
0 Ohm
0W
0 %
SCL
405
