Printronix P7000 Series Maintenance Manual page 547

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
1 179065-901 179065-901
2 177821-001 177821-001
3 178132-001 178132-001
4 Ref
5 178046-001 178046-001
6 Ref
7 173217-001 173217-001
8 Ref
9 178988-901 178988-901
10 204155-001 204155-001
11 250088-001 250088-001
12 177812-001 177812-001
13 Ref
14 Ref
15 Ref
16 Ref
17 173130-001 173130-001
18 Ref
19 179755-001 179755-001
20 179756-001 179756-001
21 177808-001 177808-001
22 178728-001 178728-001
23 177814-001 177814-001
24 178717-001 178717-001
25 108664-903 108664-903
26 177803-001 177803-001
Description
Tractor Set, Non-Roller, 05/10/15 (Blue)
Shaft, Spacer, Tractor, ZTP
Pad, Nylon, Mount Block, ZTP
Ref Screw, Button Head (3)
Field Kit, Paper Feed Motor, V3
Ref Screw, Hex w/Lock Washer, 10-24x.50 (2)
Plate, Tractor Shaft, Right
Ref Screw, Socket Cap, 6-32x.312 Trilob, Self-
Tapping
Splined Shaft Assembly (Blue Handle)
Tolerance Ring,.37X.25,.006 THK,SS
Field Kit, Leaf, Paper Guide, P7000, ZTP
Plate, Clamping, Paper Guide, ZTP (3)
Ref Screw, 6-32x.25, ¼ Hex Hd, Washer (6)
Ref Screw, M5X16X.8, SHCS-Thumb, SS, ASTM
F837M
Ref Bearing, Ball, Sealed
Ref Screw, Socket Cap, 6-32x.312 Trilob (Self-
Tapping) (2)
Plate, Tractor Shaft, Left
Ref Screw, Flat HD, Metric, M3x6mm (3)
Leaf, Guide, Paper, Outer, ZTP (2)
Leaf, Guide, Paper, Center, ZTP
Block, Mount, Ctr Paper Guide, ZTP
Block, Mounting, Outboard, Paper Guide,
ZTP (2)
Extrusion, Paper Guide, ZTP (3)
Field Kit, Hardware, ZTP
Belt, Timing, .080 Pitch, 100 Teeth, .500 Wide
Right Side Plate
Illustrations of ZTP Components
Notes
Part of item 24
Part of item 24
Part of item 5
Contains three front leaf
guide assemblies
Part of item 11
Part of item 11
Part of item 24
Part of item 11
Paper Feed Belt
