Printronix P7000 Series Maintenance Manual page 355

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
1 150261-901 150261-901
2 Ref
3 152415-901 152415-901
170172-001 170172-001
4 Ref
5 179638-001 179638-001
6 Ref
7 178992-902 178992-902
178992-901 178992-901
178995-001 178995-001
8 Ref
9 Ref
10 Ref
11 Ref
12 179073-901 179073-901
13 Ref
14 Ref
15 Deleted Deleted
16 Ref
17 152416-901 152416-901
173427-901 173427-901
18a 178046-001 178046-001
18b 177482-001 177482-001
19 Ref
20 Ref
21 Ref
Description
Card Cage Fan Assembly
Ref Screw, w/Lock Washer (3)
Switch Assembly, Paper Detector
Field Kit, Slotted Black Back Form Switch
Ref Screw, Thread-forming, 6-32x.375 (2)
Motor Assembly, Platen
Ref Screw, Hex w/Lock Washer, 10-24x.50 (2)
Ribbon Guide Cable Assembly, RH
Ribbon Guide Cable Assembly, LH
Field Kit, Ribbon Guide, LH/RH, P7000
Ref Washer, Flat #4
Ref Screw, w/Lock Washer, 4-40x.38
Ref Screw, w/Lock Washer, 10-32x.50 (2)
Ref Shield, Card Cage Fan
Ribbon Motor Assembly, w/Hub
Ref Screw, Hex w/Lock Washer (2)
Ref Washer, Flat #6 (2)
Deleted
Ref Screw, w/Lock Washer (2)
Hammer Bank Fan Assembly
Hammer Bank Fan Assembly
Field Kit, Paper Feed Motor, V3
Field KIt, Paper Feed Motor w/Heat Sink
Ref Screw, Hex w/Lock Washer (2)
Ref Post, Platen Belt Spring
Ref Spring, Platen Belt
Illustrations of Printer Components
Notes
Air flow is into card cage
Two 6-32x1.75 on bottom,
One 6-32x0.50 on top left
Optional switch used with
black back forms
Part of item 3
Includes pulley
Part of item 18
Part of item 7
Part of item 7
Part of item 5
6-32x.50
6-32x1.25
All except P7220; air flow
is up
P7220; air flow is up
All except P7220
P7220—Heat sink screws:
18 inch-pounds (2.03 N•m)
10-32x.50
355
