Paper Guide Leaf, Center

Removal
1. Prepare the printer for maintenance (page 520).
2. Remove the center paper guide knob and center paper guide leaf.
(See page 533, Figure 121.)
3. Remove the top button head screw, bottom flat head screw, and center
guide leaf. (See page 533, Figure 121.)
Installation
1. Reverse step 2 and step 3 of the removal procedure above.
2. Return the printer to normal operation (page 520).

Paper Guide Leaf, Front

Removal
1. Prepare the printer for maintenance (page 520).
2. Remove the left paper guide knob and the left, front paper guide leaf.
(See page 533, Figure 121.)
3. Repeat step 2 to remove the center and right, front paper guide leaves.
Installation
1. Reverse step 2 and step 3 of the removal procedure above.
2. Return the printer to normal operation (page 520).

Paper Guide Leaf, Outer

Removal
1. Prepare the printer for maintenance (page 520).
2. Remove the left paper guide knob and the left, front paper guide leaf.
(See page 533, Figure 121.)
3. Remove the top button head screw, bottom flat head screw, and left outer
guide leaf. (See page 533, Figure 121.)
4. Repeat step 2 through step 3 to remove the right outer leaf guide.
Installation
1. Reverse step 2 through step 4 of the removal procedure above.
2. Return the printer to normal operation (page 520).
