Printronix P7000 Series Maintenance Manual page 553

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
1 152415-901 152415-901
170172-001 170172-001
2 Ref
3 179638-001 179638-001
4 178992-902 178992-902
178992-901 178992-901
178995-001 178995-001
5 Ref
6 Ref
7 Ref
8 179073-901 179073-901
9 Ref
10 Ref
11 Ref
12 152416-901 152416-901
173427-901 173427-901
13 Ref
14 Ref
15 Ref
Description
Switch Assembly, Paper Detector
Field Kit, Slotted Black Back Form Switch
Ref Screw, Thread-forming, 6-32x.375 (2)
Motor Assembly, Platen
Ribbon Guide Cable Assembly, RH
Ribbon Guide Cable Assembly, LH
Field Kit, Ribbon Guide, LH/RH, P7000
Ref Washer, Flat #4
Ref Screw, w/Lock Washer, 4-40x.38
Ref Screw, w/Lock Washer, 10-32x.50 (2)
Ribbon Motor Assembly, w/Hub
Ref Screw, Hex w/Lock Washer (2)
Ref Washer, Flat #6 (2)
Ref Screw, w/Lock Washer (2)
Hammer Bank Fan Assembly
Hammer Bank Fan Assembly
Ref Screw, Hex w/Lock Washer (2)
Ref Post, Platen Belt Spring
Ref Spring, Platen Belt
Illustrations of ZTP Components
Notes
Optional switch used with
black back forms
Part of item 1
Includes pulley
Part of item4
Part of item 4
Part of item 3
6-32x.50
6-32x1.25
All except P7220; air flow
is up
P7220; air flow is up
10-32x.50
553
