Printronix P7000 Series Maintenance Manual page 341

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
1 Ref
2 150261-901 150261-901
3 Ref
4 Ref
5 Ref
6 142013-901 142013-901
7 Ref
Description
Ref Nut, 6-32 (1)
Card Cage Fan Assembly
Ref Fan Guard
Ref Screw, w/Lock Washer (4)
Ref Card Cage, Pedestal
Circuit Breaker
Ref Baffle, Power Supply, Ped, P7000
Illustrations of Printer Components
Notes
Upper right fan corner only
Air flow is into card cage
6-32x1.75
341
