Printronix P7000 Series Maintenance Manual page 545

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
3 179074-901 250297-901
179074-991 250297-991
179075-901 250251-901
179075-991 250251-991
179076-901 250410-901
179076-991 250410-991
4 Ref
5 Ref
6 179077-901 250298-901
179077-991 250298-991
7 202362-001 202362-001
8 152421-901 152421-901
9 152420-901 152420-901
10 164805-901 164805-901
11 202362-001 202362-001
12 152439-901 152439-901
13 152440-901 152440-901
15 Ref
16 204480-902 250488-902
204480-903 250488-903
17 Ref
18 178046-001 178046-001
178535-001 178535-001
19 Ref
20 Ref
21 Ref
22 179990-001 179990-001
23 Ref
24 Ref
25 250128-001 250128-001
26 204535-901 250489-901
Description
Power Supply, PFC, 5/10
Power Supply, PFC, 5/10, Adv Exch
Power Supply, PFC, 15
Power Supply, PFC, 15, Adv Exch
Power Supply, PFC, 20
Power Supply, PFC, 20, Adv Exch
Ref P101 Cable Connector
Ref Cable Assembly, AC-In, Power Supply
Controller PCBA, (V5)
Controller PCBA, (V5) Adv Exch
Housing, Connector Kit
Hammer Bank Logic Cable Assembly
Shuttle Motor Cable Assembly
Hammer Bank Power Cable Assembly
Housing, Connector Kit
Centronics I/O Cable Assembly
Control Panel Cable Assembly
Ref Screw, Captive, Power Supply (2)
SIMM, Flash Memory, 8 MB
SIMM, Flash Memory, 16 MB
Ref Security Key
Paper Feed Motor
Paper Feed Motor
Ref Integrated Print Management System Bar
Code Sensor (179526-901) Cable
Ref Not Used
Ref
Not Used
Paper Feed Assembly, ZTP
Ref Screw w/Lociwasher and Flat Washer
Ref Screw, Hex w/Lockwasher, 8X.38
Cover Plate, Right Extension
SDRAM DIMM, MEM, 32 MB, PC100
Illustrations of ZTP Components
Notes
P7005, -10,- 02H, -03H
P7005, -10,- 02H, -03H
P7015, P7X06H
P7015, P7X06H
P7008H, P7000HD
P7008H, P7000HD
Part of item 3
Part of Field Kit, AC Assy,
153502-901
P106, Motor Sensor, Left
Used on all except P7220
P107, Motor Sensor, Right
Install in slot J11. J10 is not
used.
P7X05/10/15
P7X05/10/15LG
Not spared as an assembly
545
