Default Interface
IP Method
IP A ddress
Subnet Mask
Gateway IP
DNS Server 1
DNS Server 2
User Name
Password
Layer 2 QoS
802.1Q/VLAN Tag
Layer 2 QoS 802.1p
Priority Value
Method: Route
•
WAN port interface is used for uplink connection;; LAN port interface is used as a router. Please see a
sample diagram below.
Firmware Version 1.0.2.5
If "Dual" is selected as "Method", users will need assign the default interface to be
LAN 1 (mapped to UCM6510 WAN port) or LAN 2 (mapped to UCM6510 LAN port)
and then configure network settings for LAN 1 and LAN 2. The default interface is
LAN 2.
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Enter the subnet mask address for static IP settings. The default setting is
255.255.0.0.
Enter the gateway IP address for static IP settings when the port is assigned as
default interface. The default setting is 0.0.0.0.
Enter the DNS server 1 address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 2 address for static IP settings.
Enter the user name to connect via PPPoE.
Enter the password to connect via PPPoE.
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value is
0.
Assign the priority value of the layer 2 QoS packets for LAN port. The default value
is 0.
