Time Condition
Start Time
End Time
Date
Week
Destination
INBOUND R OUTE: P REPEND E XAMPLE
UCM6510 now allows user to prepend digits to an inbound DID pattern, with strip taking precedence over
prepend. With the ability to prepend digits in inbound route DID pattern, user no longer needs to create
multiple routes for the same trunk in order to route calls to different extensions.
Firmware Version 1.0.2.5
Select the start time "hour:minute" for the trunk to use the inbound rule.
Select the end time "hour:minute" for the trunk to use the inbound rule.
Select "By Week" or "By Day" and specify the date for the trunk to use the
inbound rule.
Select the day in the week to use the inbound rule.
Select the destination for the inbound call under the defined time condition.
Extension
•
Voicemail
•
Conference Room
•
Call Queue
•
Ring Group
•
Paging/Intercom
•
Voicemail Group
•
Fax
•
DISA
•
IVR
•
By DID
•
When "By DID" is used, the UCM6510 will look for the destination
based on the number dialed, which could be local extensions,
conference, call queue, ring group, paging/intercom group, IVR,
voicemail groups and Fax extension as configured in "DID
destination". If the dialed number matches the DID pattern, the call will
be allowed to go through.
Configure the number of digits to be stripped in "Strip" option.
Dial By Name
•
