Other Settings
SRTP
Fax Mode
Strategy
Skip Trunk A uth
Codec Preference
SEARCH A ND E DIT E XTENSION
All the UCM6510 extensions are listed under web GUI-­>PBX-­>Basic/Call Routes-­>Extensions, with
status, Extension, CallerID Name, Technology (SIP, IAX and FXS), IP and Port. Each extension has a
checkbox for users to "Modify Selected Extensions" or "Delete Selected Extensions". Also, options
"Edit" , "Reboot"
specifying the extension number to find an extension quickly.
Firmware Version 1.0.2.5
authentication credentials are shared between physical endpoints. The
default setting is "Yes".
Enable SRTP for the call. The default setting is "No".
Select Fax Mode for this user. The default setting is "None".
None: Disable Fax.
•
Fax Detect: Fax signal from the user/trunk during the call can be
•
detected and the received Fax will be sent to the Email address
configured for this extension. If no Email address can be found for the
user, the Fax will be sent to the default Email address configured in
Fax setting page under web UI-­>PBX-­>Internal Options-­>Fax/T.38.
This option controls how the extension can be used on devices within
different types of network.
Allow A ll
Device in any network can register this extension.
Local Subnet Only
Only the user in specific subnet can register this extension. Up to
three subnet addresses can be specified.
A Specific IP A ddress.
Only the device on the specific IP address can register this extension.
The default setting is "Allow A ll".
If enable "All", users do not need to enter password when making an
outbound call. If enable "Follow Me", the call can dial out via follow me
without password.
Select audio and video codec for the extension. The available codecs are:
PCMU, PCMA, GSM, AAL2-­G.726-­32, G.722, G.729, G.723, ILBC,
ADPCM, LPC10, H.264, H.263 and H.263p.
and "Delete" are available per extension. User can search an extension by
UCM6510 IP PBX User Manual Page 132 of 317
