3-­Way Calling
Send CallerID A fter
Fax Mode
Call Transfer
Call Forward Unconditional
CFU Time Condition
Call Forward No A nswer
CFN Time Condition
Firmware Version 1.0.2.5
The default setting is "ON", which is 128 taps.
Configure to enable/disable 3-­way calling feature on the user. The default
setting is enabled.
Configure the number of rings before sending CID. Default setting is 1.
For FXS extension, there are three options available in Fax Mode. The
default setting is "None".
None: Disable Fax.
•
Fax Detect: Fax signal from the user/trunk during the call can be
•
detected and the received Fax will be sent to the Email address
configured for this extension. If no Email address can be found for the
user, the Fax will be sent to the default Email address configured in
Fax setting page under web UI-­>PBX-­>Internal Options-­>Fax/T.38.
Fax Gateway: If selected, the UCM6510 can support conversation
•
and processing of Fax data from T.30 to T.38 or T.38 to T.30. This
feature is only available for FXS or FXO port.
Table 41: FXS Extension Configuration Parameters – Features
Configure the Call Forward Unconditional target number. If not
configured, the Call Forward Unconditional feature is deactivated. The
default setting is deactivated.
Select time condition for Call Forward Unconditional. CFU takes effect
only during the selected time condition. The available time condition are
"Office Time", "Out of Office Time", "Holiday", "Out of Holiday", "Out of
Office Time or Holiday" and "Specific".
Note:
"Specific" has higher priority to "Office Times" if there is a conflict in
•
terms of time period.
Specific time can be configured on the bottom of the extension
•
configuration dialog. Scroll down the add Time Condition for specific
time.
Office Time and Holiday could be configured on page Settings-­>Time
•
Settings-­>Office Time/Holiday page.
Configure the Call Forward No Answer target number. If not configured,
the Call Forward No Answer feature is deactivated. The default setting is
deactivated.
Select time condition for Call Forward No Answer. The available time
condition are "Office Time", "Out of Office Time", "Holiday", "Out of
Holiday", "Out of Office Time or Holiday" and "Specific".
UCM6510 IP PBX User Manual Page 125 of 317
