USE T HE L ED I NDICATORS
The UCM6510 has LED indicators in the front to display connection status. The following table shows the
status definitions.
LED Indicator
Power 1/Power 2
PoE
LAN
WAN
USB
SD
Phone 1 /Phone 2 (FXS)
Line 1/Line 2 FXO
T1/E1/J1
Firmware Version 1.0.2.5
time.
Hardware Testing
•
Select "Test SVIP" to perform SVIP test on the device. This is mainly for
factory testing purpose which verifies the hardware connection inside the
device. The diagnostic result displays on the LCD after the test is done.
Protocol: Web access protocol. HTTP or HTTPS. By default it's HTTPS
•
Port: Web access port number. By default it's 8089
•
Enable SSH: Enable SSH access.
•
Disable SSH: Disable SSH access.
•
By default the SSH access is disabled.
Table 4: UCM6510 LED INDICATORS
LED Status
Solid: Connected
Fast Blinking: Data Transferring
Slow Blinking: Trying to connect
OFF: Not Connected
Solid: Connected and working
Fast Blinking (0.5s on/0.5s off): No cable is
connected;; or connected but the link is not
working at all.
Slow Blinking (1s on/1s off): Connected but
the link is only working one-­way
UCM6510 IP PBX User Manual Page 32 of 317
