Ring Delay
Hold A ccess
SAMPLE C ONFIGURATION
1. On the UCM6510, go to web UI-­>Basic/Call Routes-­>Analog Trunks page. Create analog trunk or
edit the existing analog trunk. Make sure "SLA Mode" is enabled for the analog trunk. Once enabled,
this analog trunk will be only available for the SLA stations created under web UI-­>Basic/Call
Routes-­>SLA Station page.
Click on "Save". The analog trunk will be listed with trunk mode "SLA".
2. On the UCM6510, go to web UI-­>Basic/Call Routes-­>SLA Station page, click on "Create New SLA
Station". Please refer to section
Users can create one or more SLA stations to monitor the analog trunk. The following figure shows two
stations, 1002 and 1005, are configured to be associated with SLA trunk "fxo1".
Firmware Version 1.0.2.5
be no timeout.
Configure the time (in seconds) for delay before ringing the station when a
call first coming in on the shared line. No delay is set by default. If set to 0,
there will be no delay.
This option defines the competence of the hold action for one particular
trunk. If set to "open", any station could hold a call on that trunk or resume
one held session;; if set to "private", only the station that places the trunk
call on hold could resume the session. The default setting is "open".
Figure 94: Enable SLA Mode for Analog Trunk
Figure 95: Analog Trunk with SLA Mode Enabled
CREATE/EDIT SLA STATION
[
UCM6510 IP PBX User Manual
for the configuration parameters.
]
