External calls External calls are calls sent from one trunk to another trunk, which are not sent to any
internal extension.
Inbound Trunks Select certain inbound trunk(s) and the CDR of calls going inbound through the
trunk(s) will be filtered out.
Outbound Trunks Select certain outbound trunk(s) and the CDR of calls going outbound through the
trunk(s) will be filtered out.
Caller Number Enter the caller number to filter the CDR report. CDR with the matching caller number
will be filtered out.
User could specify a particular caller number or enter a pattern. '.' matches zero or
more characters, only appears in the end. 'X' matches any digit from 0 to 9,
case-­insensitive, repeatable, only appears in the end.
For example:
3XXX: It will filter out CDR that having caller number with leading digit 3 and of 4 digits
length.
3.: It will filter out CDR that having caller number with leading digit 3 and of any length.
Caller Name Enter the caller name to filter the CDR report. CDR with the matching caller name will
be filtered out.
Callee Number Enter the callee number to filter the CDR report. CDR with the matching callee number
will be filtered out.
Start Time Specify the start time to filter the CDR report. Click on the calendar icon on the right
and the calendar will show for users to select the exact date and time.
End Time Specify the end time to filter the CDR report. Click on the calendar icon on the right
and the calendar will show for users to select the exact date and time.
The call report will display as the following figure shows.
Users could perform the following operations on the call report.
Firmware Version 1.0.2.5
Figure 167: Call Report
