Detect Model: Semi-­auto Detect.
Source Channel: The source channel to be detected.
Destination Number: The number to be dialed for detecting. This number could be a cell phone
number or other PSTN number that can be reached from the source channel PSTN number.
5. Click "Detect" to start detecting. The source channel will initiate a call to the destination number. For
"Auto Detect", the call will be automatically answered. For "Semi-­auto Detect", the UCM6510 web GUI
will display prompt to notify the user to answer or hang up the call to finish the detecting process.
6. Once done, the detected result will show. Users could save the detecting result as the current
UCM6510 settings.
Detect Model
Firmware Version 1.0.2.5
Figure 84: UCM6510 PSTN Detection: Semi-­Auto Detect
Table 46: PSTN Detection for Analog Trunk
Select "Auto Detect" or "Semi-­auto Detect" for PSTN detection.
Auto Detect
•
Please make sure two or more channels are connected to the
UCM6510 and in idle status before starting the detection. During the
detection, one channel will be used as caller (Source Channel) and
another channel will be used as callee (Destination Channel). The
UCM6510 will control the call to be established and hang up between
caller and callee to finish the detection.
Semi-­auto Detect
•
Semi-­auto detection requires answering or hanging up the call
manually. Please make sure one channel is connected to the
UCM6510 and in idle status before starting the detection. During the
