The following table shows the configuration parameters for 802.1X on UCM6510. Identity and MD5
password are required for authentication, which should be provided by the network administrator obtained
from the RADIUS server. If "EAP-­TLS" or "EAP-­PEAPv0/MSCHAPv2" is used as the 802.1X mode, users
will also need upload 802.1X CA Certificate and 802.1X Client Certificate, which should be also generated
from the RADIUS server.
802.1X Mode
Identity
MD5 Password
802.1X CA Certificate
802.1X Client
Certificate
STATIC R OUTES
A static route is a pre-­determined path that the network traffic travels to reach a specific host or network.
On the UCM6510, the static route function allows the device to use manually configured routes, rather
than dynamically assigned routes or default gateway configured in the UCM6510 web GUI-­>Network
Settings-­>Basic Settings to forward traffic. It can be used to define a route when no other routes is
Firmware Version 1.0.2.5
Figure 21: UCM6510 Using 802.1X EAP-­MD5
Table 9: UCM6510 Network Settings-­>802.1X
Select 802.1X mode. The default setting is "Disable". The supported 802.1X mode
are:
EAP-­MD5
•
EAP-­TLS
•
EAP-­PEAPv0/MSCHAPv2
•
Enter 802.1X mode identity information.
Enter 802.1X mode MD5 password information.
Select 802.1X certificate from local PC and then upload.
Select 802.1X client certificate from local PC and then upload.
