DIRECT O UTWARD D IALING ( DOD) V IA V OIP T RUNKS
The UCM6510 provides Direct Outward Dialing (DOD) which is a service of a local phone company (or
local exchange carrier) that allows subscribers within a company's PBX system to connect to outside lines
directly.
Example of how DOD is used:
Company ABC has a SIP trunk. This SIP trunk has 4 DIDs associated to it. The main number of the office
is routed to an auto attendant. The other three numbers are direct lines to specific users of the company.
At the moment when a user makes an outbound call their caller ID shows up as the main office number.
This poses a problem as the CEO would like their calls to come from their direct line. This can be
accomplished by configuring DOD for the CEO's extension.
Steps on how to configure DOD on the UCM:
1. To setup DOD go to UCM6510 web GUI-­>PBX-­>Basic/Call Routes-­>VoIP Trunks page.
2. Click to access the DOD options for the selected SIP Trunk.
3. Click "Create a new DOD" to begin your DOD setup.
4. For "DOD Number" enter one of the numbers (DIDs) from your SIP trunk provider. In the example
above Company ABC received 4 DIDs from their provider. ABC will enter in the number for the CEO's
direct line.
5. Select an extension from the "Available Extensions" list. Users have the option of selecting more than
one extension. In this case, Company ABC would select the CEO's extension. After making the
selection, click on the
Firmware Version 1.0.2.5
The maximum number of concurrent calls using the trunk. The default
settings 0, which means no limited.
Select Fax mode. The default setting is "None".
None: Disable Fax.
•
Fax Detect: Fax signal from the user/trunk during the call can be
•
detected and the received Fax will be sent to the Email address
configured for this extension. If no Email address can be found for the
user, the Fax will be sent to the default Email address configured in
Fax setting page under web UI-­>PBX-­>Internal Options-­>Fax/T.38.
button to move the extension(s) to the "Selected Extensions" list.
UCM6510 IP PBX User Manual Page 174 of 317
