UCM6510 supports SLA that allows mapping the key with LED on a multi-­line phone to different external
lines. When there is an incoming call and the phone starts to ring, the LED on the key will flash in red and
the call can be picked up by pressing this key. This allows users to know if the line is occupied or not. The
SLA function on the UCM6510 is similar to BLF but SLA is used to monitor external line i.e., analog trunk
on the UCM6510. Users could configure the phone with BLF mode on the MPK to monitor the analog trunk
status or press the line key pick up call from the analog trunk on the UCM6510.
CREATE/EDIT S LA S TATION
SLA Station can be configured on web GUI-­>PBX-­>Basic/Call Routes-­>SLA Station.
Click on "Create New SLA Station" to add a SLA Station.
•
Click on to edit the SLA Station. The following table shows the SLA Station configuration
•
parameters.
Click on to delete the SLA Station.
•
Station Name
Station
Available SLA Trunks
Selected SLA Trunks
SLA Station Options
Ring Timeout
Firmware Version 1.0.2.5
SLA S TATION
Figure 93: SLA Station
Table 62: SLA Station Configuration Parameters
Configure a name to identify the SLA Station.
Specify a SIP extension as a station that will be using SLA.
Existing A nalog Trunks with SLA Mode enabled will be listed here.
Select a trunk for this SLA from the Available SLA Trunks list. Click on
to arrange the order. If there are multiple trunks selected, when
there are calls on those trunks at the same time, pressing the LINE key on
the phone will pick up the call on the first trunk here.
Configure the time (in seconds) to ring the station before the call is
considered unanswered. No timeout is set by default. If set to 0, there will
UCM6510 IP PBX User Manual Page 176 of 317
