PCMA  Override
Boost  Ringer
Fast  Ringer
Low  Power
Ring  Detect
FXS  MWI  Mode

















Firmware  Version  1.0.2.5

(TISS).  The  default  setting  is  No.

If  enabled,  users  can  select  the  impedance  value  for  Two-­Wire  Impedance
Synthesis  (TISS)  override.  The  default  setting  is  600Ω.
Select  the  codec  to  be  used  for  analog  lines.  North  American  users  should
choose   PCMU.   All   other   countries,   unless   already   known,   should   be
assumed  to  be  PCMA.  The  default  setting  is  PCMU.
Note:
This  option  requires  system  reboot  to  take  effect.
Configure   whether   normal   ringing   voltage   (40V)   or   maximum   ringing
voltage  (89V)  for  analog  phones  attached  to  the  FXS  port  is  required.  The
default  setting  is  "Normal".
Configure  to  increase  the  ringing  speed  to  25HZ.  This  option  can  be  used
with  "Low  Power"  option.  The  default  setting  is  "Normal".
Configure  the  peak  voltage  up  to  50V  during  "Fast  Ringer"  operation.  This
option  is  used  with  "Fast  Ringer".  The  default  setting  is  "Normal".
If  set  to  "Full  Wave",  false  ring  detection  will  be  prevented  for  lines  where
Caller  ID  is  sent  before  the  first  ring  and  proceeded  by  a  polarity  reversal,
as  in  UK.  The  default  setting  is  "Standard".
Configure  the  type  of  Message  Waiting  Indicator  on  FXS  lines.  The  default
setting  is  "FSK".
FSK:  Frequency  Shift  Key  Indicator
•
NEON:  Light  Neon  Bulb  Indicator.
•
UCM6510  IP  PBX  User  Manual


Page  146  of  317
