Sync LDAP Port
LDAP Outbound Rule
LDAP Dialed Prefix
CC Settings
Enable CC
CC Max A gents
CC Max Monitors
Type
Provider Name
Host Name
Keep Trunk CID
Username
Password
Disable This Trunk
Firmware Version 1.0.2.5
during the LDAP sync process. The password must be the same on both
UCM6510 peers to ensure successful synchronization.
Configure the TCP port used LDAP sync feature between two peer
UCM6510.
Specify an outbound rule for LDAP sync feature. The UCM6510 will
automatically modify the remote contacts by adding prefix parsed from
this rule.
Specify the prefix for LDAP sync feature. The UCM6510 will automatically
modify the remote contacts by adding this prefix.
If enabled, the system will automatically alert the user when a called party
is available, given that a previous call to that party failed for some reason.
Configure the maximum number of CCSS agents which may be allocated
for this channel. In other words, this number serves as the maximum
number of CC requests this channel is allowed to make. The minimum
value is 1.
Configure the maximum number of monitor structures which may be
created for this device. In other words, this number tells how many callers
may request CC services for a specific device at one time. The minimum
value is 1.
Table 59: Create New IAX Trunk
Select the VoIP trunk type.
Peer IAX Trunk
•
Register IAX Trunk
•
Configure a unique label to identify this trunk when listed in outbound
rules, inbound rules and etc.
Configure the IP address or URL for the VoIP provider's server of the
trunk.
If enabled, the trunk CID will not be overridden by extension's CID when
the extension has CID configured. The default setting is "No".
Enter the username to register to the trunk from the provider when
"Register IAX Trunk" type is selected.
Enter the password to register to the trunk from the provider when
"Register IAX Trunk" type is selected.
If selected, the trunk will be disabled.
Table 60: IAX Register Trunk Configuration Parameters
