IP A ddress
Subnet Mask
Gateway IP
DNS Server 1
DNS Server 2
User Name
Password
Layer 2 QoS
802.1Q/VLAN Tag
Layer 2 QoS 802.1p
Priority Value
LAN (when Method is set to "Route")
IP A ddress
Subnet Mask
DHCP Server Enable
DNS Server 1
DNS Server 2
Allow IP A ddress From Enter the DHCP IP Pool starting address. The default setting is 192.168.2.100.
Allow IP A ddress To
Default IP Lease Time
LAN (when Method is set to "Switch")
IP Method
IP A ddress
Subnet Mask
Gateway IP
DNS Server 1
DNS Server 2
User Name
Password
Layer 2 QoS
802.1Q/VLAN Tag
Layer 2 QoS 802.1p
Priority Value
LAN 1 / LAN 2 (when Method is set to "Dual")
Firmware Version 1.0.2.5
Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Enter the subnet mask address for static IP settings. The default setting is
255.255.0.0.
Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 1 address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 2 address for static IP settings.
Enter the user name to connect via PPPoE.
Enter the password to connect via PPPoE.
Assign the VLAN tag of the layer 2 QoS packets for WAN port. The default value is
0.
Assign the priority value of the layer 2 QoS packets for WAN port. The default value
is 0.
Enter the IP address assigned to LAN port. The default setting is 192.168.2.1.
Enter the subnet mask. The default setting is 255.255.255.0.
Enable or disable DHCP server capability. The default setting is "Yes".
Enter DNS server address 1. The default setting is 8.8.8.8.
Enter DNS server address 2. The default setting is 208.67.222.222.
Enter the DHCP IP Pool ending address. The default setting is 192.168.2.254.
Enter the IP lease time (in seconds). The default setting is 43200.
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Enter the subnet mask address for static IP settings. The default setting is
255.255.0.0.
Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 1 address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 2 address for static IP settings.
Enter the user name to connect via PPPoE.
Enter the password to connect via PPPoE.
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value is
0.
Assign the priority value of the layer 2 QoS packets for LAN port. The default value
is 0.
