The UCM6510 supports ring group feature with different ring strategies applied to the ring group members.
This section describes the ring group configuration on the UCM6510.
CONFIGURE R ING G ROUP
Ring group settings can be accessed via web GUI-­>PBX-­>Call Features-­>Ring Group.
Click on "Create New Ring Group" to add ring group.
•
Click on to edit the ring group. The following table shows the ring group configuration parameters.
•
Click on to delete the ring group.
•
Ring Group Name
Extension
Ring Group Members
Ring Strategy
Permission
Custom Prompt
Firmware Version 1.0.2.5
RING G ROUP
Figure 110: Ring Group
Table 72: Ring Group Parameters
Configure ring group name to identify the ring group. Letters, digits, _ and -­
are allowed.
Configure the ring group extension.
Select available users from the left side to the ring group member list on
the right side. Click on
Select the ring strategy. The default setting is "Ring in order".
Ring simultaneously
•
Ring all the members at the same time when there is incoming call to
the ring group extension. If any of the member answers the call, it will
stop ringing.
Ring in order
•
Ring the members with the order configured in ring group list. If the first
member doesn't answer the call, it will stop ringing the first member
and start ringing the second member.
Assign permission level to the user. The available permissions are
"Internal", "Local", "National" and "International" from the lowest level to
the highest level. The default setting is "Internal".
This option allows user to customize prompt for a ring group to announce
UCM6510 IP PBX User Manual
to arrange the order.
