2. Enter the old password first.
3. Enter the new password and retype the new password to confirm. The new password has to be at
least 4 characters. The maximum length of the password is 16 characters.
4. Click on "Save" and the user will be automatically logged out.
5. Once the web page comes back to the login page again, enter the username "admin" and the new
password to login.
LDAP S ERVER
The UCM6510 has an embedded LDAP server for users to manage corporate phonebook in a centralized
manner.
By default, the LDAP server has generated the first phonebook with PBX DN
•
"ou=pbx,dc=pbx,dc=com" based on the UCM6510 user extensions already.
Users could add new phonebook with a different Phonebook DN for other external contacts. For
•
example, "ou=people,dc=pbx,dc=com".
All the phonebooks in the UCM6510 LDAP server have the same Base DN "dc=pbx,dc=com".
•
"cn" "ou" and "dc" are parts of LDAP data Interchange Format according to RFC 2849, which is how
•
the LDAP tree is filtered.
Cn= Common Name
ou= Organization Unit
dc= Domain Component
Here is an example of how the search for "ou=pbx,dc=pbx,dc=com" is performed in LDAP server
•
query.
From the dc=com Domain Component, find the dc=pbx Domain Component first. In the dc=pbx
Domain Component, find the Organizational Unit called pbx (ou=pbx) and then find the object that has
a Common Name of admin.
If users have the Grandstream phone provisioned by the UCM6510, the LDAP directory has been set up
on the phone and can be used right away for users to access all phonebooks generated in the UCM6510.
Additionally, users could manually configure the LDAP client settings to manipulate the built-­in LDAP
server on the UCM6510. If the UCM6510 has multiple LDAP phonebooks created, in the LDAP client
configuration, users could use "dc=pbx,dc=com" as Base DN to have access to all phonebooks on the
UCM6510 LDAP server, or use a specific phonebook DN, for example "ou=people,dc=pbx,dc=com", to
access to phonebook with Phonebook DN "ou=people,dc=pbx,dc=com " only.
To access LDAP Server settings, go to web GUI-­>Settings-­>LDAP Server.
