Before deploying and configuring the UCM6510 series, the device needs to be properly powered up and
connected to network. This section describes detailed information on installation, connection and warranty
policy of the UCM6510 series.
EQUIPMENT P ACKAGING
CONNECT Y OUR U CM6510
CONNECT T HE U CM6510
Follow the steps below to connect the UCM6510 for initial setup:
Firmware Version 1.0.2.5
INSTALLATION
Table 2: UCM6510 Equipment Packaging
Main Case
Power Adapter
Ethernet Cable
Wall Mount
Screws
Quick Installation Guide
Figure 1: UCM6510 Front View
Figure 2: UCM6510 Back View
UCM6510 IP PBX User Manual
Yes ( x 1)
Yes ( x 2)
Yes ( x 1)
Yes ( x 2)
Yes ( x 6)
Yes ( x 1)
Page 26 of 317
