The UCM6510 supports T.30/T.38 Fax and Fax Pass-­through. It can also convert the received Fax to PDF
format and send it to the configured Email address. Fax/T.38 settings can be accessed via web
GUI-­>PBX-­>Internal Options-­>FAX/T.38.
CONFIGURE F AX/T.38
Click on "Create New Fax Extension". In the popped up window, fill the extension, name and Email
•
address to send the received Fax to.
Click on "Fax Settings" to configure the Fax parameters.
•
Enable Error Correction Mode
Maximum Transfer Rate
Minimum Transfer Rate
Default Email A ddress
Template Variables
Firmware Version 1.0.2.5
FAX/T.38
Table 75: FAX/T.38 Settings
Configure to enable Error Correction Mode (ECM) for the Fax. The default
setting is "Yes".
Configure the maximum transfer rate during the Fax rate negotiation. The
possible values are 2400, 4800, 7200, 9600, 12000 and 14400. The
default setting is 14400.
Configure the minimum transfer rate during the Fax rate negotiation. The
possible values are 2400, 4800, 7200, 9600, 12000 and 14000. The
default setting is 2400.
Configure the Email address to send the received Fax to if user's Email
address cannot be found.
Note:
The extension's Email address or the Fax's default Email address needs to
be configured in order to receive Fax from Email. If neither of them is
configured, Fax will be not be received from Email.
Fill in the "Subject:" and "Message:" content, to be used in the Email when
sending the Fax to the users.
The template variables are:
${CALLERIDNUM} : Caller ID Number
•
${CALLERIDNAME} : Caller ID Name
•
${RECEIVEEXTEN} : The extension to receive the Fax
•
${FAXPAGES} : Number of pages in the Fax
•
${VM_DATE} : The date and time when the Fax is received
•
