Click on to edit the inbound route.
•
Click on to delete the inbound route.
•
INBOUND R ULE C ONFIGURATIONS
Trunks
DID Pattern
Privilege Level
Default Destination
Firmware Version 1.0.2.5
Table 64: Inbound Rule Configuration Parameters
Select the trunk to configure the inbound rule.
All patterns are prefixed with the "_".
•
Special characters:
•
X: A ny Digit from 0-­9.
Z: A ny Digit from 1-­9.
N: A ny Digit from 2-­9.
".": Wildcard. Match one or more characters.
"!": Wildcard. Match zero or more characters immediately.
Example: [12345-­9] -­ A ny digit from 1 to 9.
The pattern can be composed of two parts, divided by a '/' character.
•
The first part is used to specify the dialed number the second part is
used to specify the caller ID and it is optional, if set it means only the
extension with the specific caller ID is allowed to call in or call out.
For example, patter '_2XXX/1234' means the only extension with the
caller ID '1234' is allowed to use this rule.
Select privilege level for the inbound rule when a VoIP trunk is selected in
"Trunks" field.
Internal: The lowest level required. A ll users can use this rule.
•
Local: Users with Local, National or International level are allowed to
•
use this rule.
National: Users with National or International level are allowed to use
•
this rule.
International: The highest level required. Only users with international
•
level can use this rule.
This setting is used to compare with the outbound trunk's permission level
when the inbound call dials out via a trunk on the UCM6510. Therefore, it's
usually used only when the "Default Destination" is set to "By DID".
Select the default destination for the inbound call.
Extension
•
Voicemail
•
