Enable Pick Extension
Pick Extension Segment
Pick Extension Period (hour):
Please make sure an extension is manually assigned to the phone or "Automatically Assign Extension" is
enabled during provisioning. After the configuration on the UCM6510 web GUI, click on "Save" and "Apply
Changes". Once the phone boots up and picks up the config file from the UCM6510, it will take the
configuration right away.
DISCOVERY
Users could manually discover the device by specifying the IP address or scanning the entire LAN
network. Three methods are supported to scan the devices.
PING
•
ARP
•
SIP Message (NOTIFY)
•
Click on "Auto Discover" under web GUI-­> PBX-­> Zero Config-­> Zero Config, fill in the "Scan Method"
and "Scan IP". The IP address segment will be automatically filled in based on the network mask detected
on the UCM6510. If users need scan the entire network segment, enter 255 (for example, 192.168.40.255)
instead of a specific IP address. Then click on "Save" to start discovering the devices within the same
network. To successfully discover the devices, "Zero Config" needs to be enabled on the UCM6510 web
GUI-­>PBX-­>Zero Config-­>Auto Provisioning Settings.
Firmware Version 1.0.2.5
defined in web UI-­>PBX-­>Internal Options-­>General page-­>Extension
Preference section: "Auto Provision Extensions".
If enabled, the extension list will be sent out to the device after receiving
the device's request. This feature is for the GXP series phones that
support selecting extension to be provisioned via phone's LCD. The
default setting is disabled.
Click on the link "Pick Extension Segment" to specify the extension list to
be sent to the device. The default range is 4000 to 4999. Pick Extension
Segment range can be defined in web UI-­>PBX-­>Internal
Options-­>General page-­>Extension
Extensions".
Specify the number of minutes to allow the phones being provisioned to
pick extensions.
UCM6510 IP PBX User Manual
Preference section:
Page 86 of 317
