VOIP T RUNK C ONFIGURATION
VoIP trunks can be configured in UCM6510 under web GUI-­>PBX-­>Basic/Call Routes-­>VoIP Trunks.
Once created, the VoIP trunks will be listed with Provider Name, Type, Hostname/IP, Username and
Options to edit/detect the trunk.
Click on "Create New SIP Trunk" or "Create New IAX Trunk" to add a new VoIP trunk.
•
Click on to configure detailed parameters for the VoIP trunk.
•
Click on to configure Direct Outward Dialing (DOD) for the SIP Trunk.
•
Click on to start LDAP Sync.
•
Click on to delete the VoIP trunk.
•
For VoIP trunk example, please refer to the following document:
http://www.grandstream.com/products/ucm_series/ucm65xx/documents/how_to_interconnect_multiple_uc
m6510_using_peer_trunk.pdf
The VoIP trunk options are listed in the table below.
Type
Provider Name
Host Name
Keep Original CID
Keep Trunk CID
Firmware Version 1.0.2.5
VOIP T RUNKS
Table 56: Create New SIP Trunk
Select the VoIP trunk type.
Peer SIP Trunk
•
Register SIP Trunk
•
Configure a unique label to identify this trunk when listed in outbound
rules, inbound rules and etc.
Configure the IP address or URL for the VoIP provider's server of the
trunk.
Keep the CID from the inbound call when dialing out. This setting will
override "Keep Trunk CID" option. Please make sure that the peer PBX at
the other side supports to match user entry using "username" field from
authentication line.
If enabled, the trunk CID will not be overridden by extension's CID when
the extension has CID configured. The default setting is "No".
