SmartWare Software Configuration Guide
Hardware Port
Transmit Edge
Port Type
CRC Type
Max Frame Length: 2048
Recv Threshold
Encapsulation
Configuring the serial encapsulation type
The synchronous serial interface supports the Frame Relay and PPP serial encapsulation method. For more
information how to configure Frame Relay and PPP, please see Chapter15,
page 172 and Chapter 30,
To set the encapsulation method used by a serial interface, use the
configuration command.
This procedure describes how to set the encapsulation type of the serial interface.
Mode: Administrator execution
Step
node (cfg)#port serial slot port
1
node (prt-ser)[ slot/port ]#[no] encapsulation
2
{framerelay | ppp}
node (prt-ser)[ slot/port ]#show port serial
3
Example: Configuring the serial encapsulation type
The following example enables Frame Relay encapsulation for the serial interface on slot 0 and port 0. Check
that in the command output of
node(cfg)#port serial 0 0
node(prt-ser)[0/0]#encapsulation framerelay
node(prt-ser)[0/0]#show port serial
Serial Interface Configuration
------------------------------
Port
State
Hardware Port
Transmit Edge
Port Type
CRC Type
Max Frame Length: 2048
Recv Threshold
Encapsulation
Configuring the hardware port protocol
Note
Only available on certain devices.
Serial port configuration task list
: V.35
: normal
: DTE
: CRC-16
: 1
:
"PPP configuration" on page 305.
Command
show port serial
: serial 0 0 0
: CLOSED
: V.35
: normal
: DTE
: CRC-16
: 1
: framerelay
encapsulation
Selects the serial interface on slot and
port .
Sets the encapsulation type for the
selected interface.
Displays the serial interface configuration.
Encapsulation is set to framerelay.
14 • Serial port configuration
"Frame Relay configuration"
interface
Purpose
on
168
