MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3 Programming Procedures

Extensions

Extensions
3Programming Procedures
This section contains the following procedures:
Assigning outside lines or trunks to the buttons on a telephone (including
lines and trunks used for loudspeaker paging).
Copying line button assignments from one extension to either an individual
extension or a block of extensions.
Assigning the following buttons on telephones (for Hybrid/PBX systems
only):
Identifying analog multiline telephones that do not have built-in
speakerphones (BIS) or Hands-Free Answer on Intercom (HFAI) capability.
Identifying analog multiline telephone extensions that require pairing of
extension jacks to provide either the Voice Announce feature or Voice and
Data features.
Programming rotary signaling on tip/ring ports.
Assigning tip/ring functionality on 412/016 ETR (enhanced tip/ring) module.

Assign Trunks or Pools to Extensions

Use this procedure to assign outside lines/trunks (connected to the control unit) to
specific buttons on each telephone. The lines/trunks assigned to a button on a
telephone are called personal lines.
This procedure is used only to change or add personal lines, Loudspeaker
Paging, or Pool buttons (Hybrid/PBX only) to telephones. See
System Access Buttons'' on page 3-279
System Access (SA) buttons.
!
SECURITY ALERT:
In Release 6.0 and later systems (Hybrid/PBX mode only), do not assign
private networked lines as personal lines on telephone buttons. Do not
assign pools of private network trunks (tandem PRI or tandem tie) to
telephones. Do not provide dial access to these pools. Use ARS to provide
access to a remote networked system's trunks for making outside calls.
System users can reach extensions on the remote system by using normal
inside calling procedures.
— System Access or Intercom Voice
— System Access or Intercom Ring
— System Access or Intercom Originate Only
— Shared System or Intercom Access
3
3
to add or change Intercom (ICOM) or
Issue 1
April 1999
3-268
''Assign Intercom or
