MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
1
Programming Basics
System Programming Console

Console Components

Table 1-1
MLX-20L Console and the Direct Station Selector (DSS). Refer to
the location of the components.
Table 1-1.
MLX-20L Console Components
Component
Desk Stand
(not shown)
Button Labeling
Cards
Contrast Control
(not shown)
Fixed Feature
Buttons
Dialpad
Direct Station
Selector (DSS)
Display Buttons
Display Screen
Handset
LEDs
Line Buttons
and
Table 1-2
provide descriptions of the components that make up the
Function
An adjustable stand on the console and the DSS, allows a 20- or 30-
degree viewing angle.
Cards labeled with the number or feature assigned to each line button.
A sliding control at the top of the console, used to brighten or dim the
display screen.
Eight fixed display buttons for most-used features.
Feature for viewing the Feature screen and selecting features.
HFAI (Hands-Free Answer on Intercom) for answering
voice-announced calls without the handset.
Mute for turning the speakerphone's microphone on and off.
Speaker for talking on a call through the speakerphone without lifting
the handset.
Transfer for sending a call to another telephone.
Conf for adding a line or extension to a conference call.
Drop for disconnecting an extension or line from a conference call.
Hold for putting a call on hold.
Number pad for dialing telephone numbers.
A device that adds extension buttons and other buttons to the console.
See
Table
1-2.
Four fixed display buttons and 10 unlabeled buttons used to view the
different screens and select names, features, and options from the
display screen. See
''Console Buttons'' on page
Screen with a 7-line by 24-character display area that shows call
information, features, prompts, date, and time.
The hand-held part of the console you pick up, talk into, and listen from.
(Light-Emitting Diodes) The lights on the console that assist in checking
feature status.
Twenty buttons to make and receive calls; unlabeled buttons are
programmable for one-step feature use.
1
1-6.
Issue 1
April 1999
1-5
Figure 1-1
