MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3 Programming Procedures
DS1 Facilities
Console Display/Instructions
6. Save your entry.
7. Return to the System Programming menu.
All Tie-Trunk Procedure
Console/Display Instructions
1. Specify the emulated trunks as TIE-PBX, Toll, or S56 Data.
All TIE Type Slot xx:
Select one
TIE-PBX
Toll
S56 Data
Exit
2. Save your entry.
3. Return to the System Programming menu.
u
S56 Data Procedure
Console Display/Instructions
1. Enter the channel number (nn = 1 to 24).
S56 Data Lines Slot xx:
Enter channel num (1–24)
Backspace
Exit
Additional Information
Select Enter.
Select Exit four times.
Additional Information
TIE-PBX: Transmit-receive loss set to 0/4.
Toll: Channels used for network
S56 Data: Channels used for data.
Enter
Select TIE-PBX,
Toll,
or S56 Data.
Select Enter.
Select Exit four times.
Additional Information
xx = slot number entered in Step 3.
Delete
Dial or type [nn].
Enter
3
xx = slot entered in Step 3
services transmit receive loss set to 0/6.
3
Issue 1
April 1999
3-119
