MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3 Programming Procedures
Uniform Dial Plan Routing
Console Display/Instructions
12. Return to the System Programming menu.

UDP Other Digits

Use this procedure to specify other (extra) digits that must be added by the
system to the beginning of the dialed digits when calls are placed on an identified
route. You may need to prepend a digit in order to accommodate the 5-digit
numbering of DEFINITY Communications System extensions in your private
network. For more information about techniques for handling these non-local dial
plan extension numbers, see
3-31.
The user does not use a Pool button or pool dial-out code. The dialed digits,
therefore, correspond to the non-local dial plan numbering.
NOTES:
A maximum of 20 digits can be added, in any combination of digits 0 through 9.
Special characters such as switchhook flash, Stop, and # cannot be included as
extra digits. Pause is allowed in every position except the first.
Summary: UDP Other Digits
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
''Non-Local Dial Plan Extension Ranges'' on page
UDP pool routes must be programmed before you assign digit
absorption.
Do not use this procedure to overcome conflicts between local and
remote extension numbering. Such conflicts can result in numerous
problems with system features.
System Manager
Hybrid/PBX
Not required
Non-Local Dial Plan Administration Form in the
Installation Specification
0
Up to 20 digits (any combination of 0 to 9)
No
No
Additional Information
Select Exit four times.
3
3
Issue 1
April 1999
3-589
