Lucent Technologies MERLIN LEGEND Release 7.0 System Programming Manual page 319

MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3 Programming Procedures
DS1 Facilities
Console Display/Instructions
10. Enter the channel number (nn = 1 to 24).
**** slot xx:
Enter channel num (1 to 24)
Backspace
Exit
11. Assign or remove the channel.
12. Continue to assign the channel to another slot or go to Step 13.
13. Save your entry.
14. Return to the System Programming menu.
Additional Information
If you selected S56 Data, go to:
u
If you selected ALL S56 Data, go to:
l
**** = option name selected in Step 8
xx = slot entered in Step 3
Delete
Next
Enter Dial or type [nn].
Select Enter
or Delete.
You may continue to assign or remove
additional channels by repeating steps
10 and 11.
Select Next.
Return to Step 10. The next slot is
displayed on Line 1.
Select Enter.
Select Exit four times.
S56 Data Procedure.
All S56 Data Procedure.
Issue 1
April 1999
3-117
