Ars Restriction Level For Extensions - Lucent Technologies MERLIN LEGEND Release 7.0 System Programming Manual

MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3 Programming Procedures
Optional Extension Features
Console/Display Instructions
5. Enter the logical ID of the last extension in the block (nnn = 1 to 144).
Start at extension xxxx:
Enter ending extension
Logical id (1 – 144)
Backspace
Exit
6. Save your entry.
7. Return to the System Programming menu.

ARS Restriction Level for Extensions

Use this procedure to assign an ARS restriction level to an extension. Outgoing
calls can be made only to routes that have a Facility Restriction Level (FRL) lower
than or equal to that of the extension for which the call is being made. Only
outgoing calls are affected; users can receive inside, local, and toll calls on
restricted telephones and can join any type of call in progress.
The restriction level assigned to extensions is opposite to the FRL assigned to
routes, where 0 is the most and 6 is the least restrictive.
In Release 6.0 and later systems, FRLs assigned to extensions apply not only to
ARS calls, but also to calls for non-local dial plan extensions connected by private
trunks to your local system. For this reason, use care in assigning FRLs both to
extensions and to UDP routes. For example, if a user must be restricted from toll
calls on your local system, you may need to plan UDP routes' FRLs to allow the
user to reach necessary non-local dial plan extensions. For details, see
Dial Plan Routing'' on page
Summary: Assigning ARS Restriction Level For
an Extension
Programmable by
Mode
Idle Condition
Additional Information
xxxx = extension entered in Step 1
Enter Dial or type #[nnn].
Select Enter.
Select Exit three times.
3-579.
System Manager
Hybrid/PBX only
Not required
3
3
Issue 1
April 1999
3-334
PC
Ã
''Uniform
