MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3
Programming Procedures
Data Features
Console Display/Instructions
4. Enter the voice (odd-numbered) extension number of the pair (nnnn).
Data Voice/Data
Enter voice/data pair
Backspace
Exit
5. Assign or remove the voice/data pair.
6. Return to the System Programming menu.
2B Data
Use this procedure to program an MLX port for 2B data capability. Assigning a
port for 2B data allows both B-channels of a single MLX port to be used for
speeds up to 128 Kbps on data calls. 2B data capability is available in
Release 4.0 and later.
Consider the following when programming ports for 2B data capability:
The extension number of the port cannot be the first or fifth port on an MLX
module. These ports are designated as potential operator ports and cannot
be used for 2B data connections.
The extension number must correspond to the adjunct extension number of
an MLX port. By default, these extensions begin with "7".
Devices that are not intended for 2B data should not be connected to a port
programmed for 2B data. These devices probably will not work.
Additional Information
The system automatically assigns the
data (even-numbered) extension. Use the
Inspect feature (Inspct button or
view the pair.
Delete
Enter
SP: "Entering an Extension"
Select Enter
or Delete.
You may continue to assign or remove
additional voice/data pairs by repeating
Steps 4 and 5.
Select Exit.
3
Issue 1
April 1999
3-634
PC
) to
Ã
