1 Programming Basics
Programming Procedures

Using Enter

Pressing Enter to save your entry produces one of the following results:
The next screen in the procedure appears.
The screen does not change and you can enter another extension or line/
trunk. In most of these cases, Delete is also an option. Enter is used
either to assign the extension to a group or to assign a feature to the
extension. Delete is used to remove the extension from a group or to
remove the feature from the extension.
The procedure is complete and you return to a previous screen.
Console/Display Instructions
1. Specify the extension.
BIS/HFAI Extensions:
Enter extensions
xxxx
Backspace
Exit
2. Assign or remove BIS/HFAI capability.
3. Return to the System Programming menu.

Using Next

When you are programming a feature that can apply to a sequence of extensions,
lines/trunks, or groups, the screen key Next appears on the console display. Next
( on the PC) permits you to save your current entry and display the next
number in the sequence. You can continue to press Next until you finish
programming the entire sequence. When the last number in the sequence
displays on the screen, press Enter (
entry and move to the next step of the procedure. Procedures that allow the use of
Additional Information
Delete
SP: "Entering an Extension"
Enter
Select Enter
or Delete.
You may continue to assign or remove
BIS/HFAI capability to additional
extensions by repeating Steps 1 and 2.
Select Exit twice.
1
1
or on the PC) to save the final
Issue 1
April 1999
1-21
