MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3
Programming Procedures
Memory Card
If any type of programming is taking place at an extension during the automatic
backup procedure, the backup is canceled. The system does not re-attempt the
backup.
If an automatic backup fails for any reason (including a system-busy condition), all
of the programmed alarm buttons on system operator consoles light and the
information is recorded in both the permanent error log and the last 10 error logs.
The system does not re-attempt the backup.
Also see
''Backup Messages'' on page 3-651
occur during the automatic backup procedure.
NOTE:
If an automatic backup fails for any reason (except when the failure results
because the memory card is write-protected), the automatic backup feature
is turned off. Follow the procedure below to reprogram automatic backups.
Summary: Automatic Backup
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
for information about errors that may
3
System Manager
All
Not required (No extensions are allowed to be in
programming mode, including the system
programming console)
1, System Planning
Weekly backup: Sunday at 2:00 am
(if daily backup is selected, time is factory set for
2:00 am)
Daily: hhmm (00 to 23; 00 to 59)
Weekly: dhhmm (0 to 6; 00 to 23; 00 to 59)
No
No
To program daily backup:
Insert memory card
Auto Backup
Daily
00–59)
Enter
Exit
To program weekly backup:
Insert memory card
Auto Backup
Weekly
(0–6;00–23; 00–59)
System
Back/Restore
Drop
Dial time (00–23;
Exit
System
Back/Restore
Drop
Dial day and time
Enter
Exit
Exit
Issue 1
April 1999
3-647
