2 Programming with SPM
Accessing SPM
The password prompt appears on the screen when the connection is
made. (You may have to press
prompt.)
If the PC is in a remote location and your system has not activated the
Remote Access feature, do the following:
NOTE:
If you enter a telephone number of fewer than 11 digits, you must end it with
a pound sign (#).
To access SPM through a local or remote modem connection, follow the steps
below:
1. Set up the appropriate physical connections between the PC and the control unit.
See ''Connecting the PC'' on page
2. Type spm and press
Welcome to SPM
The MERLIN LEGEND
System Programming &
& Maintenance Utility
Please press any key
to continue
Version X.XX
If you wish to program in a language other than the current language set for SPM,
see ''Language'' on page
3. Press any key to display a blank screen on which you can enter modem
commands. (You may have to press the key several times.)
4. Make a data connection to the modem of the control unit.
See ''Modem Connections'' on page
password prompt appears as shown in Step 5.
— Use the main telephone number to place a voice call to the system
on the line to which the modem is connected.
— Instruct the operator to transfer you to the modem (press Transfer,
dial *10, then hang up the telephone).
— To put the modem on line, type ATH1 and press
up the telephone.
to display the SPM Welcome screen shown below.
2-42.
more than once to get the password
2-13.
X.XX = current version of SPM
2-19. When the connection is made, the
Issue 1
April 1999
2-20
, then hang
