2 Programming with SPM

Accessing SPM

NOTE:
Remote access (modem connection) has priority over local access (direct
connection), unless a backup or restore procedure is in progress through a
direct local connection. If a modem connection is attempted while any other
type of onsite programming is in progress (either at the system or at a
directly connected PC), the system sends a message to the onsite
programmer. The message indicates that a modem connection is being
established and the onsite programming session is terminated.
Accessing SPM
The procedure for accessing SPM depends on whether your PC is connected to
the control unit with a modem (either local or remote) or without a modem (direct).
This section covers both of these access procedures.

Direct Local Connection

To access SPM when your PC is connected directly to the control unit, follow the
steps below:
1. Set up the appropriate physical connections between the PC and the control unit.
See ''Connecting the PC'' on page
2. If you installed SPM on the hard disk of the PC, go to Step 5;
or if SPM is not installed on the hard disk, insert the SPM disk into Drive A.
3. Type a: and press
A:> appears on the screen.
4. Type spm and press
Welcome to SPM
The MERLIN LEGEND
System Programming
& Maintenance Utility
Please press any key
to continue
Version X.XX
5. Press any key to display the SPM Main Menu.
SPM Main Menu
Menu: Select Function
Sys Program
Backup
Boards
.
to display the SPM Welcome screen shown below.
X.XX = current version of SPM
Maintenance
Restore
Pass-Thru
2
2
2-13.
