2 Programming with SPM

Connecting the PC

8. Press the function key that corresponds to the desired option.
SPM Main Menu
Menu: Select Function
Sys Program
Backup
Boards
Print Opts
Monitor
NOTE:
The function keys shown on either side of the display are included here for
quick reference. See
PC keys in SPM.
Connecting the PC
There are three ways to connect the PC to the control unit. Choose the method
below that is most useful for your installation.

Direct local connection

Local modem connection
Remote modem connection
Direct Local Connection
For a direct local connection, you must connect the PC to the system
programming jack. This is the lower modular RS-232 jack on the processor
module, as shown in
printer.)
To connect a PC more than fifty feet from the control unit, see
For direct local connections, the system supports speeds of 1,200 and 2,400 bps.
NOTE:
You must use a direct local connection to program in surrogate mode.
— If the PC is connected to the processor, the SPM Main Menu
appears as shown in Step 8.
— If the PC is not connected, go to
Maintenance
Restore
Pass-Thru
Password
Language
''SPM Screens'' on page 2-22
