MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
3 Programming Procedures
System Renumbering
Console Display/Instructions
5. The last extension number in the range is displayed. Delete the range.
NonLocal UDP Start: nnnn :
Enter ending number
xxxx
Backspace
Exit
6. Return to the System Programming menu.

Direct Station Selector (DSS) Page Buttons

Use this procedure to set the three Page buttons on the DSS to correspond to the
system numbering plan. This procedure assigns extension numbers to DSS
buttons. You cannot program individual buttons on a DSS; this is the only method
for programming DSS buttons.
Page button assignment should be sequential. If only one DSS is attached, each
Page button assignment sets the console for a range of 50 extension numbers:
Page 1: 0 to 49; Page 2: 50 to 99; Page 3: 100 to 149.
If two DSSs are attached, each Page button assignment sets the console for a
range of 100 extension numbers. If two DSSs are attached to the console, change
the factory setting so that the difference between extension numbers assigned to
the range is at least 100. For example, assign Page 1 to begin with extension 10,
Page 2 to begin with extension 110, and Page 3 to begin with extension 210.
Operator Park Zone codes must be included in the extension number range
specified for one of the Page buttons.
!
CAUTION:
Select Exit on the console, or
procedure. If you press Home, extensions may remain in the forced idle
condition (the LED next to each DSS button is on), and the system may
have to be restarted.
Additional Information
nnnn = number entered in Step 3
xxxx = ending number in range that
begins with nnnn.
DelRange
Enter
Select Exit two times.
3
on the PC, when you have finished this
Issue 1
April 1999
3-38
PC
