Local Or Remote Modem Connection - Lucent Technologies MERLIN LEGEND Release 7.0 System Programming Manual

MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
2 Programming with SPM
Accessing SPM

Local or Remote Modem Connection

The method you use to access SPM by modem depends on whether you are
programming onsite (locally) or from a remote location.
If you are onsite, the modem must be connected to a T/R jack on an
012 (T/R) or 016 (T/R) module, or to a jack that has been programmed for
T/R on a 412 LS-ID-ETR or 016 ETR module on the control unit. To
establish a connection to the control unit's internal modem, dial *10.
If you are at a remote location, do either of the following:
Considerations
Review the following items before you begin the modem connection procedure.
Set the Programming Language
If you prefer to program in a language other than the current SPM language
setting, see
Modem Connections
You must make a data connection to a modem. The following modem dialing
commands are for Hayes
commands your modem uses; refer to the user guide that came with your modem
for specific information.
If the PC is in the same location as the control unit, type *10.
If the PC is in a remote location and your system has the Remote Access
feature activated, type the following and press
— Place a call to the system on a Remote Access line, enter the barrier
code (if required), and dial the code for the internal modem (*10).
— Place a voice call to the system using the line to which the modem is
connected and ask the operator to transfer you to the modem (press
Transfer, dial *10, then hang up the telephone). When you hear the
modem answer tone, switch to data mode.
''Language'' on page
®
and Hayes-compatible modems. These may not be the
— Without barrier codes, type:
ATDT; the remote access telephone number; and W*10.
For example: ATDT12015551234 W*10
— With barrier codes, type:
ATDT; the remote access telephone number; and the barrier code
preceded by a "W" and W*10. The barrier code in the example below
is 555555.
For example: ATDT12015551234 W555555 W*10
2
2
2-42.
Issue 1
April 1999
2-19
:
.
.
