MERLIN LEGEND Communications System Release 7.0
System Programming 555-670-111
2 Programming with SPM
Using SPM
Table 2-5.
Board Type
412LS/ETR
016ETR
800DID
400E&M
100D
100D-U
800BRI
Follow the steps below to assign modules:
1. At the SPM Main Menu, press
SPM Main Menu
Menu: Select Function
Sys Program
Backup
Boards
Print Opts
Monitor
2. Press the function key that corresponds to the module you want to select.
Boards:
Make a selection
408LSA
012TR/OPT
800DID
800GLS
Exit
Board Types — Continued
Description
4 loop-start line jacks with Caller ID capability with 2 touch-tone
receivers and 12 ETR extension jacks including 4 with tip/ring
functionality
16 ETR extension jacks including 6 with tip/ring functionality
with 4 touch-tone receivers
8 DID trunk jacks with 2 touch-tone receivers
4 E&M tie trunk jacks
1 DS1 jack (24 channels) (Prior to Release 7.0, Common
Channel Signaling (CCS) was an option for T1; for Release 7.0
and later systems, CCS is not an option for T1.)
1 DS1 jack (24 channels); Upgradable with PCMCIA card
8 BRI trunk jacks (16 channels)
Maintenance
Restore
Pass-Thru
Password
Language
>
800LS
008ATL
008MLX
400GLR
400LSR
to select Boards.
Issue 1
April 1999
2-33
