fill pattern A graphic design for surfaces that are cut or shown in projection. You can use fill patterns for
model patterns and drafting patterns.
For more information, see
Floor fill pattern
fill volume The amount of fill (material) required to prepare a site for construction. For example, in the
following drawing, the red area indicates the cut volume, and the blue area indicates the fill volume required
to level the site for a building. See
filled region A 2D, view-specific graphic. You can use filled regions to represent various surfaces, such as
concrete or compacted earth. You can add a filled region to a detail view, a drafting view, or an annotation
family. For each filled region, you can specify a boundary line style and a fill pattern.
For more information, see
Fill Patterns on page 459.
Reporting Cut and Fill Volumes on a Site
Filled Region on page 1153.
on page 964.
Glossary | 1481
