System Management

Table 14 describes the menu items available on the System Management screen. Default values
appear in brackets.
Table 14. BIOS Setup System Management Screen Menu Items
Menu Item
Quiet Boot
Service Boot
>Console Redirection
OS Boot Timeout
BMC Revision
HSC Revision
Table 15. Setup Console Redirection Sub Menu Items
Sub Menu Item
Serial Console
Redirection
Baud Rate
Flow Control
Intel® SR870BN4 Server System Product Guide
Default Value Description
[Enabled] Selecting this option enables the BIOS to display the OEM
Disabled logo during POST. If disabled, the BIOS displays the normal
POST messages.
This option is hidden if the BIOS does not detect a valid logo
in the flash area reserved for this purpose.
Enabling this option disables serial redirection.
[Disabled] Enabling this item allows the user to boot into Service
Enabled Partition Boot mode. The item automatically resets to
"Disabled" on the next system boot.
Press <Enter> Selecting this option allows the user to configure for console
to present redirection.
selection
submenu
[Enabled] Sets the time allowed for booting an OS, from media or PXE.
Disabled
5 minutes
10 minutes
15 minutes
20 minutes
[BMC_Rev] The currently loaded version of Baseboard Management
Controller firmware. The user cannot change this value. It
appears for informational purposes only.
[HSC_Rev] Information field only, hidden if not detected. Displays the Hot
Swap Controller revision.
Default Value Description
Enabled/Disabled When enabled, Console Redirection uses only COM2.
Choosing "Disabled" completely disables Console
Redirection.
9600 When Console Redirection is enabled, use the baud rate
[19.2K] specified. When EMP is sharing the COM port as console
redirection, the baud rate must be set to 19.2K to match
38.4K
EMP baud rate.
57.6K
115.2K
No Flow Control No flow control.
[CTS/RTS] CTS/RTS = Hardware based flow control.
CTS/RTS + CD CTS/RTS +CD = Hardware based + Carrier Detect flow
control. When EMP is sharing the COM port as console
XON/XOFF
redirection, the flow control must be set to CTS/RTS or
CTS/RTS+CD depending on whether a modem is used.
