4 Hot-swapping System Components

Tools and Supplies Needed

Pen or pencil
Antistatic wrist strap (recommended)

Equipment Log

To record the model and serial numbers of the server, all installed options, and any other pertinent
information about the server, see Appendix B
on page 286.

Hot-swapping System Fans

The four 120-mm cooling fans are mounted in pairs below the back top cover of the chassis. You
can remove and install these fans without turning the server system power off. Each fan uses an
amber LED to indicate the failed fan. When an LED lights, the user needs to replace the fan.
WARNING
Make sure that the rack is anchored securely so it will not tilt forward
when the server chassis is extended. A crush hazard exists should the
rack tilt forward which could cause serious injury.
CAUTION
Do not leave the back top cover open or a system fan removed for longer
than two minutes; system cooling is reduced.
1. If the chassis is rack-mounted, slide the chassis out far enough to expose the back top cover
(see warning above).
2. Unlatch the back top cover by pressing the latches (A in Figure 49) and sliding the cover (B in
Figure 49).
Intel® SR870BN4 Server System Product Guide
Equipment Log and Configuration Worksheet",
163
