Delete Control
This drop-down box is enabled only if the Enable Line Editing box is checked. This option allows
the user to specify the delete control sequence for the BMC to use when <Delete> or
<Backspace> is pressed. Users can choose from the following:
The BMC outputs <Delete> when <Backspace> or <Delete> is received.
The BMC outputs <Backspace><Space><Backspace> when <Backspace> or
<Delete> is received.
Turn BMC Echo of Received Characters On
This check box allows the user to enable or disable the BMC echoing characters it receives when in
terminal mode. This feature is enabled when the box is checked.
Enable Handshake When BMC Ready To Receive Another Message
This setting enables or disables whether the BMC handshakes when ready to receive another
message from the user. When enabled, the BMC outputs the following string when it is ready to
accept another message from the remote console:
[SYS]<newline>
Checking the box enables this feature.
Newline Output Sequence (BMC to console)
This setting allows the user to select the characters that the BMC uses as a newline sequence when
the BMC writes a line to the console when in terminal mode. The choices are
<CR><LF>
<NULL>
<CR>
<LF><CR>
<LF>
No termination sequence
Newline Input Sequence (console to BMC)
This setting allows the user to select the characters the console uses as a newline sequence when
writing to the BMC when the BMC is in terminal mode. The choices are
<CR>
<NULL>
