LSI SCSI Utility

The LSI SCSI utility allows the user to configure the SCSI capabilities of the server. This
configuration utility can be accessed using an EFI-based utility provided by Intel. This utility is
available on the Resource CD or from Intel
representative for more information on obtaining this utility.
The EFI utility can be evoked from the EFI shell prompt with the command EFICnfg.efi. From
here the SCSI drives can be configured. The utility contains help information at the bottom of each
screen. More information on this utility will be documented in a future revision of this document.
NOTE
This utility is still being defined and changes may occur in the menus shown
below. Entrance into this utility may be updated in a future revision of this
document.
To run the LSI SCSI utility:
1. From the EFI Shell, run EFICnfg.efi to enter the LSI Logic SCSI Utility. The following
information is displayed on your monitor:
Intel's EFI Configuration program ver 0.6 Serial # Controller description
1. OnBoard Function0 Usb Universal Host Controller
2. OnBoard Function1 Usb Universal Host Controller
3. OnBoard Function0 LSI Logic Ultra320 SCSI Controller
4. OnBoard Function1 LSI Logic Ultra320 SCSI Controller
Please enter a serial number (Enter 0 to Exit):
2. Select the Function0 LSI Logic Ultra320 SCSI Controller's serial number (in this case, 3) and
press <Enter>.
60
®
Business Link (IBL). Please contact your Intel
Intel® SR870BN4 Server System Product Guide
