Specific POST Code Modules

SAL-A Module
Table 50. SAL-A POST Codes (BSP Only)
Code Number Meaning
0x8FE0 Reset Condition
0x8FD0 Node BSP selection
0x8FC0 Early node init (SNCPEIM)
0x8FB0 Processor health/setup (CVDR PEIM)
0x8FA0 PAL/FW health status
0x8F70 Memory Initialization Entry
0x8F71 RAC Initialization (Mem_DoRacInitialization())
0x8F72 Validate DIMMs (Mem_ValidateInstalledConfiguration())
0x8F73 Program MIRs/MITs (Mem_DoMirMitProgram())
0x8F74 Calculate CAS (Mem_CalcSysCas())
0xCF74 Calculate CAS Error Loop
0x8F75 Program CAS (Mem_SetMrhdCasLatency())
0x8F76 Set Mrhd DIMM Geomentry (Mem_SetMrhdDimmGeometry())
0x8F77 Perform SLEW rate calibration (Mem_DoSlewRateCalibration)
0x8F78 Mem_InitDimmAndSetCasLatencyAndBurst()
0x8F79 DDR delay Calibration (Mem_DoDdrDelayCalibration())
0x8F80 DIMM path latency Calibration
0x8F81 DIMM Strobe Delay Calibration
0x8F82 Configure SNC timing
0x8F83 Set timings for write pattern
0x8F90 Levelization
0x8F98 Reconfigure memory
0xCF9F Levelization failed. No Memory Found
0x8F60 Memory Test
0x8F50 Platform Discovery
0x8F40 SBSP selection; ICHx device detection
0xCF40 ICHx device not found
0x8F50 Platform Init
0x8F20 Memory Autoscan entry
0x8F21 Process Auto Scan Input
0x8F22 Process Auto Scan Output
0x8F10 Recovery code entry
0x8EC0 Recovery Process Started
0x8EC1 Searching for Recovery Media
0x8EC2 Loading Recovery File
0x8EC3 Validating Recovery File
0x8EC4 Unlocking Flash Devices
0x8EC5 Erasing Flash Contents
Intel® SR870BN4 Server System Product Guide
Display
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
North
South
South
South
South
South
South
271
